Refrigerated Incubators – Air-jacketed

Air-jacketed Refrigerated Incubators by Jeiotech feature a spacious 254L chamber, ideal for diverse laboratory applications. A bright VFD display with 0.1 °C resolution ensures accurate temperature control. Dual delayed on/off timers and a preset function improve usability, while a built-in outlet with safety cover supports safe device operation.

The inner tempered glass door allows for convenient sample monitoring, and rounded chamber corners make cleaning and airflow maintenance easier. Explore our range of laboratory equipment at Apex Scientific, South Africa, and visit our Insights page to learn more.

Air-jacketed Refrigerated Incubators provide reliable temperature control and robust safety features for laboratory environments. Designed by Jeiotech and available from Apex Scientific in South Africa, these incubators are ideal for sensitive applications requiring stable conditions. They offer a precise temperature range from 4°C to 70°C, making them suitable for a variety of scientific experiments.



Accurate Temperature Control

These air-jacketed refrigerated incubators use microprocessor PID control and three-point temperature calibration to ensure accuracy. Natural convection is achieved through a heater and fan located within the air jacket, which promotes even heat distribution across the chamber. As a result, samples remain protected under consistent environmental conditions.



Built-in Safety Features

For added reliability, the incubators automatically resume operation after a power failure, minimizing workflow disruption. Moreover, they include over-current protection and a triple independent temperature monitoring system. This system features alarms for both high and low temperature deviations, along with electronic and mechanical over-temperature limiters. The keypad lock function prevents accidental setting changes during use. In addition, audible and visible alarms notify users immediately if the door remains open, preserving internal stability.

Accessories

Learn More

For additional insights and guidance, read our article, Choosing the Right Incubator for Your Laboratory: A Guide from Apex Scientific in South Africa. Visit our Insights page for more helpful resources, including detailed articles on various products and their laboratory applications.

ModelIL3-15AIL3-25A
Chamber volume (L / cu ft)156 / 5.5254 / 8.97
Refrigerator (Hp)1 / 6 HBP1 / 6 HBP
TemperatureRange (℃ / ℉)4 to 70 / +39.2 to 158
Fluctuation 1) at 37℃ (±℃ / ℉)0.2 / 0.36
Variation 1) at 37℃ (±℃ / ℉)0.7 / 1.26
Dimension (W×D×H)Interior (mm / inch)600×520×500/ 24×20.5×20500×540×940/ 20×21.3×37
Exterior (mm / inch)770×790×1115/ 30×31.1×43.9670×805×1668/ 26.4×31.7×65.7
No. of wire shelf (standard / max.)2 / 113 / 25
Net weight (Kg / lbs)108 / 238.1145 / 319.7
Electrical requirements (230V)60Hz, 6.6A50Hz, 6.6A60Hz, 8.0A50Hz, 8.0A
Cat. No.AAH220612KAAH220612KAAH220712KAAH220712K
Electrical requirements (120V)60Hz, 10.2A60Hz, 12.3A
Cat. No.AAH220632UAAH220732U
Electrical requirements (230V, 50/60Hz, A)4.56.46.68
Cat. No.AAH220412KAAH220512KAAH220612KAAH220712K
Electrical requirements (120V, 60Hz, A)8.310.610.212.3
Cat. No.AAH220462UAAH220562UAAH220632UAAH220732U
SKUDescription
AAH220612KIL3-15A Low Temperature Incubator, Air-Jacketed
AAH220712KIL3-25A Low Temperature Incubator, Air-Jacketed
