General Heating Bath

General heating bath by Jeiotech delivers precise temperature control from ambient +7℃ to 100℃, ideal for laboratory applications in South Africa. Featuring a microprocessor PID controller with automatic tuning, it ensures accuracy. The digital LED display, dual timer modes, and programmable functions enhance usability.

Its corrosion-resistant stainless-steel construction supports various bath fluids. Safety features include an isolated heater and sensor, over-temperature protection, and warning alarms. Designed for efficiency and reliability, this laboratory equipment is available at Apex Scientific. Explore our range today and access valuable Insights to optimize your lab setup.

The Jeiotech general heating bath provides accurate temperature control ranging from ambient +7 ℃ up to 100 ℃. It is a reliable and versatile solution for laboratory applications in South Africa. Equipped with a microprocessor PID controller, this unit offers automatic tuning and calibration to ensure consistent and accurate heating.



User-Friendly Design for Maximum Efficiency

The Jeiotech heating bath includes an easy-to-read digital LED display with 0.1 ℃ resolution, improving usability during daily lab work. It also offers dual wait on/off timer modes, ranging from 1 minute to 99 hours and 59 minutes, providing excellent flexibility for timed heating protocols.

Moreover, programmable functions make it suitable for critical research, quality control, and regulatory testing. In addition, a built-in memory function allows quick access to three frequently used temperature settings, which helps streamline routine processes.



Durable and Versatile Construction

Built with corrosion-resistant stainless steel, the bath chamber supports both water and silicone fluids. Its low-profile reservoir design maximizes bench space while offering convenient access to samples. Therefore, it fits easily into any laboratory layout without compromising capacity or usability.



Advanced Safety Features

The Jeiotech general heating bath is engineered with comprehensive safety in mind. The isolated heater and sensor are protected by a baffle plate, which prevents direct contact with users and samples. This minimizes the risk of accidents and contamination.

A full protection system includes alarms for low fluid levels, dry-running, over-temperature, and over-current situations. Additionally, the splash-proof keypad enhances operational reliability, even in demanding lab environments.

Accessories


For more information and helpful guidance, read our article, Laboratory Water Baths Demystified: How to Select the Ideal Model for Your Lab. Visit the Apex Scientific Insights page for more expert advice or explore our complete range of products to find the ideal solution for your lab.

ModelBW3-05GBW3-10GBW3-20G

Bath volume (L / cu ft)

3.5 / 0.1

11.5 / 0.4

20 / 0.7

Temperature

Working temperature range (℃ / ℉)

Amb. +7 to 100 / Amb. +12.6 to 212

Temperature stability at 50℃ (±℃ / ℉)

0.4 / 0.72

0.3 / 0.54

0.3 / 0.54

Heat up time to 70℃ (min) (±℃ / ℉)

34

36

44

Dimension

Bath opening / depth (W×L, D) (mm / inch)

240×136, 150/ 9.4×5.4, 5.9

300×240, 200/ 11.8×9.5, 7.9

498×300, 200/ 19.6×11.8, 7.9

Exterior with gable cover (W×L×H) (mm / inch)

307×200×264/ 12.1×7.9×10.4

360×300×294 / 14.2×11.8×11.6

564×356×294 / 22.2×14×11.6

Net weight (kg / lbs)

6.5 / 14.3

10 / 22

18.5 / 40.8

Electrical requirements (230V, 50 / 60Hz)

3A4.3A8.7A

Cat. No.

AAH41305KAAH41315KAAH41325K

Electrical requirements (120V, 50 / 60Hz)

5.8A8.3A8.3A

Cat. No.

AAH41306UAAH41316UAAH41326U
SKUDescription
AAH41305KBW3-05G Heating Bath, 3.5LT
AAH41315KBW3-10G Heating Bath, 11.5LT
AAH41325KBW3-20G Heating Bath, 20LT

Insights Article: Laboratory Water Baths Demystified: How to Select the Ideal Model for Your Lab

Product Enquiry Handbook: Baths and Circulators

Operating Manual
