Centrifuge - Varispin 15 | Apex Scientific South Africa

The Varispin 15 – Centrifuge from Cryste offers exceptional versatility and performance for your laboratory needs. This multi-purpose centrifuge is designed to accommodate a wide range of tubes, ensuring it meets various application requirements in South Africa.

Versatile Tube Coverage

The Varispin 15 supports an impressive range of tube sizes, from 0.2ml to 750ml. This flexibility makes it suitable for different users and applications, allowing you to efficiently handle a variety of samples.

Energy Efficiency

In alignment with our commitment to ESG values, the Varispin 15 includes energy-saving features such as a Standby Off function. This ensures efficient energy use without compromising performance.

User-Friendly Operation

The CRYSTE FLIP Touch Controller features a 4.3″ full-color LCD that simplifies parameter settings. All set points are visible at a glance, and the touchpad lock prevents misuse during operation, enhancing both safety and usability. Thus, lab personnel can quickly adjust settings and focus on their experiments, improving overall efficiency.

Safety Features

For laboratories handling hazardous materials, the Varispin 15 offers a Biocontainment Accessory Package. This option isolates aerosols containing infectious agents, ensuring the safety of experimenters. It is certified by TUV NORD in compliance with IEC61010-2-020:2016 Annex AA.

Security and Quiet Performance

Unauthorized access can be restricted with password protection, ensuring ideal security for your laboratory operations. Additionally, the well-balanced motor minimizes vibration, resulting in remarkably silent operation.

For expert advice and more options, explore The Ultimate Guide to Finding the Right Centrifuge for Your Lab on the Insights page from Apex Scientific. There, you’ll find a collection of informative articles to help you better understand our products and their wide range of laboratory applications.

Model		Varispin 15
Max. RPM		15,000RPM (Angle Rotor)	4,000RPM (Swing Rotor)
Max. RCF		23,847 xg	3,667 xg
Max. Capacity		85ml x 6	750ml x 4
Accel / Decel phase		0 ~ 9 (10set)
Noise Level		≤60dB
Set Time		99-hour 59 min 59sec or continuous
Time Count		From start / From set-up RPM
Program		100 memory
Rotor ID		Automatic Recognition
Display		4.3” LCD Touch Screen
Display message on screen		RPM, RCF, Time, Door open/close, ACC, DEC, Rotor ID, Program, key lock
RPM Range		400 to 15,000 rpm
Available Rotor Quantity		13
	V15-MB	AC 230V ± 10%, 50-60Hz, 1Phase
Power Supply	V15-MBT	AC 120V ± 10%, 50-60Hz, 1Phase
	V15-MBJ	AC 100V ± 10%, 50-60Hz, 1Phase
Power Consumption		1,5KW
Dimension (W x D x H)		546 x 684 x 379 mm (H:915mm with open lid)
Weight (without rotor)		70kg

Angle Rotors

Rotor
Rotor	Fixed Angle Rotor ∠ 45′ 48 x 0.2ml Radius(mm) : 83.5		Fixed Angle Rotor ∠ 45′ 30 x 1.5ml Radius(mm) : 94.8			Fixed Angle Rotor ∠ 45′ 30 x 1.5ml Radius(mm) : 94.8			Fixed Angle Rotor ∠ 45′ 48 x 1.5ml Radius(mm) : 94.8
Item	A480.2T		A301.5T			AS301.5TX 1)			A481.5T
Tube
Volume (ml)	0.2	0.2ml Strips	0.2	0.5	1.5 / 2.0	0.2	0.5	1.5 / 2.0	0.2	0.5	1.5 / 2.0
Adaptor / tube rack	–	–									–
Item	–	–	F1.5A-0.2	F1.5A-0.5		F1.5A-0.2	F1.5A-0.5		F1.5A-0.2	F1.5A-0.5	–
Number per rack / rotor	48	6	30	30	30	30	30	30	48	48	48
Adaptor bore (mm)	6.5	6.5	6.5	8	11	6.5	8	11	6.5	8	11
Max. height for use(mm)	–	–	44	52	61	44	52	61	In 51 Out 44	In 62 Out 54	In 70 Out 61
RPM	12,000	12,000	12,000	12,000	12,000	15,000	15,000	15,000	13,000	13,000	13,000
Radius (mm)	83.5	83.5	80.3	86.7	94.8	80.3	86.7	94.8	In70.3 Out80.3	In76.7 Out86.7	In84.8 Out94.8
RCF	13,443	13,443	20,199	21,809	23,847	20,199	21,809	23,847	In 13,283 Out 15,172	In 14,492 Out 16.381	In 16,022 Out 17,912

Rotor
Rotor	Fixed Angle rotor ∠ 45′ 24 x 1.5ml Radius(mm) : 84.8
Item	A241.5T
Tube
Volume (ml)	0.2	0.5	1.5 / 2.0
Adaptor / tube rack
Item	F1.5A-0.2	F1.5A-0.5
Number per rack / rotor	24	24	24
Adaptor bore (mm)	6.5	8	11.1
Max. height for use(mm)	44	51	61
RPM	15000	15000	15000
Radius (mm)	70.3	76.7	84.8
RCF	17684	19294	21331

Rotor
Rotor	Fixed Angle Rotor ∠ 28′ 12 x 15ml Radius(mm) : 97.1	Fixed Angle Rotor ∠ 25′ 12 x 15ml Conical Radius(mm) : 100.9	Fixed Angle Rotor ∠ 30′ 6 x 50ml Radius(mm) : 99.9		Fixed Angle Rotor ∠ 25′ 6 X 50ml Conical Radius(mm) : 95.7
Item	A1215T	A1215TC	A650T		A650TC
Tube
Volume (ml)	15(16)	15 Conical	15 Conical	50	15 Conical	50 Conical
Adaptor / tube rack	–	–		–		–
Item	–	–	F50A-15C	–	F50CA-15C	–
Number per rack / rotor	12	12	6	6	6	6
Adaptor bore (mm)	19	17	17	29.5	17	30
Max. height for use(mm)	117	129	122	120	124	121
RPM	12,000	13,000	12,000	12,000	13,000	13,000
Radius (mm)	97.1	100.9	94.3	99.9	91.3	95.7
RCF	15,632	19,064	15,182	16,083	17,250	18,082

Rotor
Rotor	Fixed Angle Rotor ∠ 30′ 8 x 50ml Radius(mm) : 103.4		Fixed Angle Rotor ∠ 25′ 6 x 85ml Radius(mm) : 99.8				Fixed Angle Rotor ∠ 25′ 6 x 85ml Radius(mm) : 99.8
Item	A850T		A685T				AS685TX
Tube
Volume (ml)	15 Conical	50	15 Conical	50 Conical	50	85	15 Conical	50 Conical	50	85
Adaptor / tube rack		–								–
Item	F50A-15C	–	F85A-15C	F85A-50C	F85A-50		F85A-15C	F85A-50C	F85A-50	–
Number per rack / rotor	8	8	6	6	6	6	6	6	6	6
Adaptor bore (mm)	17	29.5	17	30	29	39	17	30	29	39
Max. height for use(mm)	123	120	123	122	118	118	123	122	118	118
RPM	12,000	12,000	12,000	12,000	12,000	12,000	12,000	12,000	12,000	12,000
Radius (mm)	97.8	103.4	90.7	94.7	95.3	99.8	90.7	94.7	95.3	99.8
RCF	15,745	16,647	14,602	15,262	15,343	16,067	14,602	15,262	15,343	16,067

A4250T

Fixed Angle Rotor ∠ 25′ 4 x 250ml Radius(mm) : 128.3
Volume (ml)	250
Number per rack / rotor	4
Adaptor bore (mm)	62
Max. height for use(mm)	123
RPM	8,000
Radius (mm)	128.3
RCF	9,180

Swing Out Rotor

S4250TE	EB250	EBS250								BW250

		Tested by TUV NORD
	S250ET -3-12	S250ET -5-12	S250ET -10-12	S250ET -15-12	S250ET -15C-9	S250ET -50-4	S250ET -50C-3	S250ET -85-2	S250EA -250	–	–
										–	–
Swing Out Rotor Max. RPM : 4,000 Radius(mm) : 182.5 Max. RCF : 3,265
Volume (ml)	3	5	10	15	15 Conical	50	50 Conical	85	250	MTP	DWT
Number per rack / rotor	12/48	12/48	12/48	12/48	9/36	4/16	3/12	2/8	1/4	4/16	1/4
Adaptor bore (mm)	13.2	13.2	16	17.2	17	29.5	29.5	38.5	62.5	–	–
Max. height for use(mm)	124	124	124	124	127	124	127	124	138	–	–
RPM	4,000	4,000	4,000	4,000	4,000	4,000	4,000	4,000	4,000	4,000	4,000
Radius (mm)	177.5	177.5	177.5	177.5	180.7	177.5	180.5	177.5	180.5	153.5	153.5
RCF	3,175	3,175	3,175	3,175	3,232	3,175	3,229	3,175	3,229	2,746	2,746

S4750T	B750	BS750								B500	BW750

		Tested by TUV NORD
	S750T -3-24	S750T -5-24	S750T -10-19	S750T -15-19	S750T -15C-14	S750T -50-7	S750T -50C-5	S750A -250
									–		–	–
Swing Out Rotor Max. RPM : 4,000 Radius(mm) : 205 Max. RCF : 3,667
Volume (ml)	3	5	10	15	15 Conical	50	50 Conical	250	750	500	MTP	DWP
Number per rack / rotor	24/96	24/96	19/76	19/76	14/56	7/28	5/20	1/4	1/4	1/4	4/16	1/4
Adaptor bore (mm)	13.2	13.2	16	17.2	17	29.5	29.5	62.5	–	70	–	–
Max. height for use(mm)	136	136	136	136	134	136	140	161	143	165
RPM	4,000	4,000	4,000	4,000	4,000	4,000	4,000	4,000	4,000	4,000	4,000	4,000
Radius (mm)	198	198	198	198	196	198	202	205	205	213	170	170
RCF	3,542	3,542	3,542	3,542	3,506	3,542	3,613	3,667	3,667	3,810	3,041	3,041

SKU	Description
CS-C-T15-MB	VARISPIN 15 – 230V±10%, 50-60Hz, 1Phase, Eu Plug, 546x684x379mm, 70Kg

Angle Rotor

SKU	Description
CS-C-T-10010	A480.2T – 0.2ml x 48 fixed angle rotor for PCR tubes (x 6 PCR strips) (Max 12,000RPM)
CS-C-T-10030	A241.5T – 1.5-2.0ml x 24 fixed angle rotor (≤15,000RPM in VARISPIN (L)15R/15, ≤12,000RPM in VARISPIN (L)12R/12)
CS-C-T-10020	A301.5T – 1.5-2.0ml x 30 fixed angle rotor (Max 12,000RPM)
CS-C-T-10032	AS301.5TX – 1.5-2.0ml x 30 fixed aerosol-tightness angle R (Axllock, ≤15,000RPM in V15R/15, ≤12,000RPM in V12R/12)
CS-C-T-10040	A481.5T – 1.5-2.0ml x 48 fixed angle(≤13,000RPM in VARISPIN (L)15R/15, ≤12,000RPM in VARISPIN (L)12R/12)
CS-C-T-10050	A1215T – 15ml x 12 fixed angle rotor (Max 12,000RPM)
CS-C-T-10061	A1215TC – 15ml x 12 fixed angle rotor for conical tubes (≤ 13,000RPM in V(L)15R/15, ≤12,000RPM in V(L)12R/12)
CS-C-T-10070	A650T – 50ml x 6 fixed angle rotor (Max 12,000RPM)
CS-C-T-10081	A650TC – 50ml x 6 fixed angle rotor for conical tubes (≤ 13,000RPM in V(L)15R/15, ≤ 12,000RPM in V(L)12R/12)
CS-C-T-10090	A850T – 50ml x 8 fixed angle rotor (Max 12,000RPM)
CS-C-T-10010	A685T – 85ml x 6 fixed angle rotor (Max 12,000RPM)
CS-C-T-10100	AS685TX – 85ml x 6 fixed aerosol-tightness angle rotor with CRYSTE Axllock(Max 12,000RPM)
CS-C-T-10112	A4250T – 250ml x 4 fixed angle rotor (Max 8,000RPM)

Swing Out Rotor

SKU	Description
CS-C-T-20010	S4250TE – 250ml 4-wing swing rotor for rectangular/well plate buckets (Max 4,000RPM)
CS-C-T-20020	S4250T – 250ml 4-wing swing rotor for round buckets (≤ 4,500RPM in V(L)15R/12R, ≤ 4,000RPM in V(L)15/12)
CS-C-T-20030	S4750T – 750ml 4-wing swing rotor for round/well plate buckets (Max 4,000RPM)
